SenseFace M2F-LR

SenseFace M2F-LR

Description

The SenseFace M2F-LR Attendance Machine is a smart face recognition and access control device…

SenseFace M2F-LR is a time and attendance terminal that simplifies workforce management while also supporting access control functions. It is designed for small and medium-sized businesses (SMEs) seeking a reliable and cost-effective solution to manage employee attendance.

SenseFace M2F-LR offers multiple authentication methods, including fingerprint verification, card access, and advanced facial authentication with an anti-spoofing function to ensure higher security and accuracy.

The device is equipped with TCP/IP and Wi-Fi connectivity for seamless network integration and secure communication. It enables fast and stable data transmission across both wired and wireless networks. Additionally, SenseFace M2F-LR supports an optional 2,000mAh backup battery, providing a minimum of 4 hours of continuous operation during power outages.

See More Details

Description

SenseFace M2F-LR – Technical Specifications

Model SenseFace M2F-LR
Display 2.8″ TFT Color LCD Screen (320 × 240)
Camera Binocular Camera @ 1MP
Operating System Linux
CPU Dual Core @ 1GHz
RAM 512 MB
ROM 8 GB
Speaker 8Ω @ 1W
Supplement Light Yes
Physical Keypad 16 Keys
Fingerprint Sensor ZK Optical Sensor
Casing Color Black and White
Authentication Methods Fingerprint / Face / Card / Password
Fingerprint Capacity 1,000 (1:N)
Face Capacity 500 (1:N)
Card Capacity 1,000
User Capacity 1,000
Transaction Capacity 150,000
Max Password Length 8 Digits
Authentication Speed ≤ 1 sec (Fingerprint) / ≤ 1.2 sec (Face)
Recognition Distance 50 cm – 180 cm (Facial)
FAR ≤ 0.02% (Face) / ≤ 0.0001% (Fingerprint)
FRR ≤ 0.05% (Face) / ≤ 0.1% (Fingerprint)
Biometric Algorithm ZKFace V4.0, ZKFingerprint V13.0
Card Type ID Card 125kHz (Standard), IC Card 13.56MHz (Optional)
Standard Functions ADMS, DST, Photo Capture, Event Photo Capture,
Schedule Bell, Tamper Switch Alarm, HTTPS / SSH Access,
Multiple Authentication, T9 Keyboard
Optional Functions IC Card, Wi-Fi, Backup Battery
Power Supply DC 12V / 3A
Backup Battery 2,000 mAh (Up to 4 hrs operation)
Operating Temperature -5°C to 45°C
Operating Humidity 10% – 90% RH
Dimensions 154 × 138 × 34 mm
Weight 1.03 kg
Supported Software ZKBio Zlink (Mobile & Cloud), ZKBio Time (On-Premise)
Installation Wall Mount (Asian / Single Gang Box)
Certifications ISO9001, ISO14001, CE, FCC, RoHS
